AM5GE
5 CHannel: 1-MIC/LINE 2-STEREO INPUT COMPACT MIXER WITH BT, TF RECORDER AND USB INTERFACE
Phonic's all-new Gold Editions of the classic AM series of mixers offer more ways to record your audio than ever before. We begin with a stereo USB interface for sending audio to and from any modern PC or Mac computer. This allows recording and/or playback of digital audio in quality far superior to the average compact disc (24-bit, 48 KHz). A superior onboard module is also included, offering both TransFlash (TF) recording and playback in addition to BT connectivity. The TF portion allows stereo recordings to be made in WAV and MP3 formats, providing phenomenal recording quality previously unavailable without additional, external equipment. Integrated stereo recording at its finest!
The AM Gold Editions still provide many of the analog standards. Ultra low-noise pre-amps ensure high quality sound when used in project studios or in sound reinforcement. Neutrik-brand microphone input connectors (both combo and XLR) are utilized for unparalleled audio while our advanced analog circuitry ensures your audio is handled with the utmost of care. The multi-band EQ on mono channels gives you total control over your audio. The AM Gold Editions also makes monitoring the mix easy with its dual multi-segment LED level meters, EFX to monitor control and high volume headphone outputs.
One balanced Mic/Line Neutrik "Combo" input with compressor and 2-band EQ
Two stereo input channels with balance and level controls
Stereo USB audio interface for PC and Mac computers (24-bit, 48 KHz)
Playback of MP3, WAV and FLAC files from TransFlash media
Internal TransFlash module for high quality stereo recording in WAV or MP3 formats
2.4GHz BT connectivity for streaming digital audio directly from smartphones and tablets
+48V phantom power for mic input
Peak and VU metering (10 segments)
Peak indicators on mono input channel
2T RTN assignable individually to Main or Headphones
Stereo RCA 2T Return input connectors plus mini-stereo connectors
5V DC power support for power banks or PC powering
Balanced master output with main rotary control
